Solar photovoltaic (PV) engineering encompasses the design, fabrication, and optimization of systems that convert incident solar irradiance into electrical power via the photovoltaic effect. Fundamentally, this effect arises from the generation of electron-hole pairs in a semiconductor material under illumination, creating a voltage across a p-n junction.

The maximum theoretical efficiency for a single-junction cell, as derived from the Shockley-Queisser limit, is approximately 33.7% under standard AM1.5G illumination (1000 W/m² at 25°C), constrained by factors such as bandgap energy, thermalization losses, and recombination. Current engineering efforts focus on mitigating these losses through material innovation, device architecture, and system-level integration, while addressing scalability, durability, and cost.

As of mid-2025, global PV deployment exceeds 1.5 terawatts (TW) cumulative capacity, with annual additions projected at 450-500 gigawatts (GW) driven by manufacturing scale-up and policy incentives like the U.S. Inflation Reduction Act. This review synthesizes the state of PV engineering, emphasizing crystalline silicon (c-Si) dominance alongside emerging thin-film and tandem technologies.

Core Photovoltaic Cell Technologies
Crystalline Silicon (c-Si) Cellsc-Si remains the backbone of PV engineering, accounting for over 95% of module production due to its mature fabrication processes and reliability. Monocrystalline silicon (mono-c-Si) cells, grown via Czochralski or float-zone methods, achieve lab efficiencies up to 26.7% through n-type passivation techniques.

Polycrystalline (poly-c-Si) variants, formed by directional solidification, lag at 22-24% but offer cost advantages via larger ingot yields. Recent advancements center on passivation and carrier-selective contacts. N-type fully passivated heterojunction (HJT) cells, combining thin amorphous silicon (a-Si) layers on c-Si wafers, reduce surface recombination via hydrogenated interfaces, yielding module efficiencies of 25.44% in 2025 records.

The heterojunction structure employs a transparent conductive oxide (TCO) like indium tin oxide (ITO) for front contacts, minimizing shading losses. Similarly, tunnel oxide passivated contact (TOPCon) cells insert a 1-2 nm SiO₂ tunnel layer beneath doped polysilicon, achieving open-circuit voltages (V_oc) >700 mV and fill factors (FF) >83%. These designs lower levelized cost of energy (LCOE) to $0.03-0.05/kWh in utility-scale applications. Bifacial c-Si modules, capturing reflected albedo from rear surfaces, boost effective efficiency by 10-30% in ground-mounted arrays, with bifaciality factors exceeding 90%.

Engineering challenges include edge passivation to prevent shunting and anti-reflection coatings (e.g., SiN_x stacks) for >4% absolute gain.

Thin-Film Technologies
Thin-film PV, deposited via chemical vapor deposition (CVD) or sputtering on substrates <10 μm thick, prioritizes low material use and flexibility. Cadmium telluride (CdTe) modules dominate at ~5% market share, with efficiencies stabilized at 22.1% via chlorine passivation to form TeCl_x interlayers, enhancing grain boundaries and V_oc to 850 mV. Copper indium gallium selenide (CIGS) cells, using co-evaporation or sequential selenization, reach 23.4% lab efficiency, benefiting from a tunable bandgap (1.0-1.7 eV) for spectral optimization. Emerging kesterite (Cu₂ZnSnS₄, CZTS) variants address toxicity concerns in CdTe/CIGS, offering earth-abundant compositions and bandgaps ~1.5 eV.
However, defect densities (10¹⁶ cm⁻³) limit V_oc deficits to 600-700 mV, necessitating alkali doping (e.g., Na, K) for improved carrier lifetimes (>10 ns).

Amorphous silicon (a-Si) and microcrystalline silicon (μc-Si) tandem cells, with efficiencies ~12-14%, excel in low-light conditions but suffer Staebler-Wronski degradation (5-10% initial loss under illumination).

Perovskite and Tandem Architectures
Perovskite solar cells (PSCs), based on ABX₃ structures (e.g., FAPbI₃, where FA⁺=formamidinium), have surged to 26.1% single-junction efficiency via vapor-assisted solution processing, leveraging defect-tolerant bandgaps (1.5-1.7 eV) and long carrier diffusion lengths (>1 μm).
Engineering focuses on halide segregation mitigation through 2D/3D heterostructures and wide-bandgap absorbers (>1.7 eV) for tandems. Two-terminal Perovskite-silicon tandems, stacking wide-bandgap Perovskites (1.6-1.8 eV) atop c-Si bottom cells, achieve certified efficiencies of 31.6% in 2025, approaching the practical limit of 43% for this configuration.

Current matching requires precise bandgap tuning via mixed cations (FA/MA/Cs) and interlayers like ITO recombination junctions. Stability remains paramount: unencapsulated PSCs degrade 20-50% in 1000 hours under 1-sun equivalent aging, addressed by carbon-graphene electrodes and UV filters. Organic photovoltaics (OPVs), using bulk heterojunctions of donor-acceptor polymers (e.g., PTB7:PCBM), hit 19% efficiency but face scalability issues in roll-to-roll printing.

Quantum dot (QD) cells, employing colloidal nanocrystals (e.g., PbS with 1.3 eV bandgap), enable multiple exciton generation for theoretical efficiencies >45%, though practical values hover at 18.1% due to ligand-induced traps.

System-Level Engineering and Balance-of-System (BOS) ComponentsPV engineering extends beyond cells to modules, inverters, and integration. Module encapsulation uses ethylene vinyl acetate (EVA) or polyolefin (POE) with glass/backsheet laminates, tested to IEC 61215 standards for 2400 Pa hail resistance and 85°C/85% RH damp heat (1000 hours, <5% degradation).

Bifacial modules incorporate transparent backsheets for rear illumination. Inverters convert DC to AC via maximum power point tracking (MPPT) algorithms, with string inverters (98% CEC efficiency) suiting utility-scale while microinverters (96-97%) optimize shade tolerance.

Energy storage integration, via lithium-iron-phosphate (LFP) batteries with 90% round-trip efficiency, addresses intermittency; hybrid systems achieve 4-6 hour dispatchability.

Grid integration employs active power control and fault ride-through per IEEE 1547, with DC-coupled architectures reducing BOS costs by 20%. Floating PV (FPV) systems, ballasted on reservoirs, mitigate land use while cooling boosts efficiency by 5-10°C.

Performance Metrics and Standardization
Key metrics include power conversion efficiency (η = P_max / (G × A), where G=irradiance, A=area), temperature coefficient (γ ≈ -0.3%/°C for c-Si), and degradation rate (0.5%/year). Standardized testing under STC ensures comparability, though field performance varies with soiling (2-5% loss) and spectral mismatch.
Lifetime projections exceed 30 years for n-type cells, with warranty guarantees at 80% retained capacity.

Challenges and Research
Despite all progress, engineering hurdles persist: Perovskite scalability (yield <90% in >1 m² modules), supply chain vulnerabilities (e.g., silver paste at 20 mg/Wp), and end-of-life recycling DirectionsDespite progress, engineering hurdles persist: Perovskite(78 Mt projected PV waste by 2050).

Transition metal oxides (e.g., TiO₂, ZnO) enhance charge extraction but require defect engineering for >10¹⁸ cm⁻³ doping densities. Future R&D prioritizes AI-optimized deposition (e.g., for uniform Perovskite films) and circular economy strategies, targeting LCOE < $0.02/kWh by 2030.

In summary, PV engineering in 2025 reflects a convergence of incremental c-Si refinements and disruptive thin-film/tandem innovations, underpinning solar's role in decarbonization. Rigorous testing and interdisciplinary modeling will dictate scalable deployment.
